4
4.33
9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
8. Remove both fuel tank bracket fasteners. Move the
fuel tank brackets out of the way for removal of fuel
tank.
9. Disconnect the fuel pump electrical harness.
10. Remove fuel tank vent hose clamp with a suitable
pliers and remove vent line from the tank vent fitting.
11. While holding a shop towel over the fuel line
connector, disconnect the quick connect fuel line
from the fuel pump. Move the fuel line out of the way
for tank removal.
NOTE: A small amount of fuel may come out of
the fuel line or tank. Properly drain fuel into a
suitable container.
12. Lift the rear of the fuel tank up first and carefully lift
the fuel tank up and out from the vehicle.
ELECTRONIC FUEL INJECTION
