1.13
9924882 - 2013–2014 RZR 800
© Copyright 2013 Polaris Sales Inc.
MODEL: 2013 RZR 4 / EPS 800
MODEL NUMBER: R13XE76AD
MODEL NUMBER: R13XE7EAI; Z14XE7EAL
Engine
Platform
H.O. Domestic Twin
Cylinder, Liquid Cooled, 4-
Stroke
Engine Number
1204671 RZR800-13
Engine Displacement
760cc H.O.
Number of Cylinders
2
Bore & Stroke (mm)
80 x 76.5 mm
Compression Ratio
11:1
Compression Pressure 165 - 185 psi
Engine Idle Speed
1250 ± 100 RPM
Engine Max Operating
RPM
6750 RPM
Lubrication
Pressurized Wet Sump
Oil Requirements PS-4 Synthetic
Oil Capacity 2 qts. / 1.9 liters
Coolant Capacity 5.5 qts. / 5.2 liters
Overheat Warning
Instrument Cluster
Indicator
Exhaust System
Dual Headpipe / Single
Silencer
Fuel System
Fuel System Type
Bosch M17 EFI
Fuel Delivery
Electronic Fuel Pump (in
tank)
Fuel Pressure
2013: 45 +/- 2 psi (310 +/-
14 kPa)
2014: 58 +/- 2 psi (400 +/-
14 kPa)
Fuel Filters
See Chapter 4
Fuel Capacity /
Requirement
7.25 gal. (27.4 liters)
87 Octane (minimum)
Electrical
Alternator Rated Output 500 Watts @ 3000 RPM
Headlights (Halogen)
2 - Halogen: Low 55 W /
High 60 W
Headlights (LED)
2 - Dual Beam LED:
Engine
Low 27 Watts; High 40
Watts
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System
Electric Start
Ignition System
Bosch M17 (ECU
Controlled)
Ignition Timing
(Variable)
3° - 10° BTDC @ 1200
RPM
Spark plug / Gap
RC7YC3 / 0.035 in. (0.9
mm)
Battery
Deka ETX30L / 30 AH
365 CCA / 12 Volt
Instrument Type
Multifunction Instrument
Cluster
DC Outlets
(2) Standard 12 Volt
Relays
Chassis / EFI / Fan
Fuel Pump / EPS
Circuit Breaker
Fan Motor: 20 Amp
Fuses (Fuse/Relay Box)
Drive / Fuel Pump: 10 Amp
Lights / EFI / Accessory: 20
Amp
Fuses (Power Fuse
Holder)
EFI: 20 Amp
Chassis / EPS: 30 Amp
Drivetrain
Transmission Type
Polaris Automatic PVT
Drive Ratio - Front 3.82:1
Drive Ratio - Final 3.70:1
Shift Type
In Line Shift - H / L / N / R
/ P
Front Gearcase
Fluid Type / Capacity
Polaris Demand Drive
6.75 oz. (200 ml)
Transmission: Main
Gearcase
Fluid Type / Capacity
Polaris AGL
24 oz. (710 ml)
Transmission: Transfer
Case
Fluid Type / Capacity
Polaris AGL
14 oz. (414 ml)
Rear Gearcase
Fluid Type / Capacity
Polaris Premium ADF
26 oz. (769 ml)
Clutch Type
Standard PVT
Drive Belt 3211133
GENERAL INFORMATION
1
