7.52
9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
Gearcase Exploded View
Ref#
Description Qty
Ref#
Description Qty
1 Screw 2 11 N/A 1
2 Screw 2 12
Axle, Spool
1
3
Bracket, Rear Mount, RH
1 13
Housing, Rear, LH
1
4
Bracket, Rear Mount, LH
1 14
Screw, Flange Head
2
5
Mount, Rear
1 15
Seal, Oil
2
6
Nut, Flanged
4 16
Screw, Flange Head
4
7
Assembly, Rear Housing, RH
1 17 Screw 8
8 N/A 1 18 Dowel 2
9
Assembly, Tapered Roller Bearing
2 19
Plug, Drain w/O-Ring
1
10 Shim 2 20
Plug, Fill w/O-Ring
1
FINAL DRIVE
