Procentec ComBricks User Manual

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 195/219
Component
Order code
Remarks
PA Coupler Monitoring Kit
101-200QBPR
• Head Station type 1B
• 1CH repeater
• PA coupler module
• Fixed backplane unit
Head Station Type 1C
101-20011C
• ProfiTrace OE on 4 networks
• 1 GB SD card
• Ethernet port
• Redundant power supply
• Drives 32 modules
• CommDTM
• Backplane unit
• Streaming in ProfiTrace 2
• OPC in ProfiTrace 2
Head Station Type 1B
101-20011B
• ProfiTrace OE on 1 network
• 1 GB SD card
• Ethernet port
• Redundant power supply
• Drives 32 modules
• Backplane unit included
• Streaming in ProfiTrace 2
• OPC in ProfiTrace 2
Head Station Type 1A
101-20011A
• Basic web server
• 1 GB SD card
• Ethernet port
• Redundant power supply
• Drives 32 modules
• Backplane unit included
• NO ProfiTrace OE
SCOPE Repeater
101-201210
• 1 RS-485 channel repeater with
oscilloscope
• Same specs as regular 1 channel
repeater
• 192 MS/s sample rate
• 50 mV resolution
• -6.436..6.436 V
• Backplane unit included
2 Channel Repeater
101-201102
• 2 RS-485 channels
• 12 Mbps
• 31 devices per channel
• Screw terminals
• DB9 connector
• Redundancy
• Termination
• Backplane unit included
