ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 196/219
Component
Order code
Remarks
1 Channel Repeater
101-201101
1 RS-485 channel
12 Mbps
31 devices per channel
Screw terminals
DB9 connector
Redundancy
Termination
Backplane unit included
2 Channel Fiber Optic Module
101-201510
2 fiberoptic channels
3 km cable length
2 x 2 ST connectors
Redundancy
Backplane unit included
Fiber Optic Ring (Multimode)
101-201530
2 fiberoptic channels
5 km cable length
2 x 2 ST connectors
Ring Redundancy
Backplane unit included
Fiber Optic Ring (Single mode)
101-201531
2 fiberoptic channels
30 km cable length
2 x 2 ST connectors
Ring Redundancy
Backplane unit included
Fiber Optic Ring (Combi mode)
101-201532
2 fiberoptic channels: one MM and one
SM
5 and 30 km cable length
2 x 2 ST connectors
Ring Redundancy
Backplane unit included
PA Link/Coupler Module
101-201610
transparent up to 1.5 mbit
trunk voltage up to 27 V
trunk current 500 mA
auto termination (in coupler mode)
Backplane unit included
SALT Repeater Module
101-201710
Adjustable termination: 94..940 Ohm
Adjustable idle voltage: 0..5 V
Same specs as regular Scope Repeater
Backplane unit included
