Operator’s Manual LTV
®
Series ventilator Page 10-5
p/n 10664, Rev. Y
High f
Use this menu item to set the high breath rate and time period alarm values. When the Total Breath
Rate ( f ) exceeds the set high breath rate and time period alarm values, an audible alarm will be
sounded and a flashing HIGH f message will be displayed.
To set the high breath rate and time period alarm values:
1) Push the Select button while HIGH f is displayed and f is displayed.
2) Push the Select button while f is displayed and HIGH f OFF or f xx bpm is displayed.
3) Turn the Set Value knob until the desired setting is displayed, push the Select button and the high
breath rate alarm value is set.
• Range: 5 - 80 bpm (in increments of 1) - HIGH f OFF
4) Turn the Set Value knob until TIME is displayed, push the Select button and xx sec is displayed.
5) Turn the Set Value knob until the desired setting is displayed and push the Select button. The
high breath rate time period alarm value is set.
• Range: 0 - 60 seconds, in increments of 10
High PEEP
Use this menu item to set a high PEEP alarm value. When the current PEEP value exceeds the set
high PEEP alarm value, an audible alarm will be sounded and a flashing HIGH PEEP message will
be displayed.
To set the high PEEP alarm value:
1) Push the Select button while HIGH PEEP is displayed.
2) HI PEEP OFF or PEEP xx cmH
2
O is displayed.
• HI PEEP OFF is the factory set default setting.
3) Turn the Set Value knob until the desired setting is displayed.
4) Push the Select button.
Range: 3 - 40 cmH
2
O (in increments of 1) - HI PEEP OFF
