Page 6-10 LTV
®
Series ventilator Operator’s Manual
p/n 10664, Rev. Y
Inspiratory Time
This control sets the length of the inspiratory period for Volume Controlled and Pressure Controlled
breaths.
The Inspiratory Time setting, along with the Volume Control setting are used to determine the peak
flow for Volume controlled breaths. While the Inspiratory Time is being updated, the Calculated Peak
Flow will be displayed in the display window.
To set the Inspiratory Time:
1) Push the Inspiratory Time button.
2) Change the setting using the Set Value knob.
Range: 0.3 - 9.9 sec
