Real Time Transducers
Use the Real Time Transducer data to view the real time activity in the ventilator. The real time
transducer menu is set up as follows:
RT XDCR DATA
AP xx.xx
c
m
H
2
0
FDb xx.xx
c
m
H
2
O
FDw xx.xx
c
m
H
2
0
FDn xx.xx
c
m
H
2
0
FTw or FTn xx.xx Lpm
FTb x.xx Lpm
LEAK xx.xx Lpm
FVd xx.xx
c
m
H
2
0
FV xx.xx Lpm
STEP xxxx
TS xxxx rpm
O2 xx.xx PSI
BV xx.xx VOLTS
EV xx.xx VOLTS
RT EXIT
Each item displays real time activity in the displayed units. For some items, transducer counts can
also be displayed. Pushing Select while the item is displayed displays additional transducer data
53
.
Display Real Time Data
AP xx.xx
c
m
H
2
0
Airway pressure as measured at the patient wye using the high side
proximal sense line.
FDb xx.xx
c
m
H
2
0
Flow differential pressure as measured at the patient wye using the bi-
directional transducer. Differential pressure is measured between the
high and low side proximal sense lines.
FDw xx.xx
c
m
H
2
0
Flow differential pressure as measured at the patient wye using the
wide scale transducer. Differential pressure is measured between the
high and low side proximal sense lines.
FDn xx.xx
c
m
H
2
0
Flow differential pressure as measured at the patient wye using the
narrow scale transducer. Differential pressure is measured between the
high and low side proximal sense lines. The narrow scale transducer is
only used for differential pressures between -0.35 cmH
2
O and 0.35
cmH
2
O (approximately -15 Lpm to 15 Lpm).
FTb xx.xx Lpm
Flow in Lpm calculated from the differential pressure measured at the
patient wye using the bi-directional transducer.
Transducer count display is not available for this item.
53
For more information, see the LTV® Series ventilator Service Manual
