Protective Boot Removal
Supplies/Tools Required:
• Replacement Screws Kit, P/N 11149
• Torque wrench (20 in-oz / 0.14 Nm to 60 in-oz / 0.42 Nm range)
• Phillips-head screwdriver
To Remove the Upper Protective Boot
82
:
1) Carefully place and support the disconnected ventilator in an upright position on a clean, dry
surface.
2) Prior to removing the mounting screws, refer to the illustration and make note of where the
screw is located in the leg of the upper boot (upper or lower hole).
WARNING
Specific Boot Replacement Screw Location - One leg of the upper protective boot has an
additional screw hole (furthest from the end of the leg);
• On earlier version ventilators (screw was located in the upper hole in the leg of the boot) the
use of a 3/16” mounting screw is required.
• On current version ventilators (screw was located in the lower hole in the leg of the boot) the
use of a 1/4” mounting screw is required.
AVERTISSEMENT
Emplacement des vis de remplacement d’un gaine spécifique – Une patte de la gaine
protectrice supérieure possède un trou de vis supplémentaire (le plus éloigné de l’extrémité de la
patte);
• Sur les anciennes versions des ventilateurs (la vis se trouvait dans le trou supérieur de la patte
de la gaine), vous devez utiliser une vis de montage de 3/16”.
• Sur la version actuelle des ventilateurs (la vis se trouve dans le trou inférieur de la patte de la
gaine), vous devez utiliser une vis de montage de 1/4”.
3) Using a Phillips screwdriver, remove the two flat-head mounting screws and finish washers in
the legs of the upper boot (c) and the two flat-head mounting screws and finish washers in the
sides of the upper boot, as indicated in the illustration on the next page.
4) Remove the upper boot and insert and thread two #4-40 pan-head mounting screws into the
screw holes in the ventilator’s back panel, as indicated in the illustration.
• Earlier version ventilators (screw was aligned with the upper hole in the boot) require the
use of the 3/16” pan-head mounting screw (e).
• Current version ventilators (screw was aligned with the lower hole in the boot) require the
use of the 1/4” pan-head mounting screw (f).
5) Insert and thread two #4-40 X 1/4” flat-head mounting screws (g) with finish washers (h) into
the screw holes in the ventilator’s side panels, as indicated in the illustration.
• Finish washers (h) should be already in place.
82
Refer to Appendix C for information concerning the appropriate accessories mounting screws or accessories
replacement screws location, type and length to use when removing or exchanging external accessories on
an LTV® Series ventilator.
