Operator’s Manual LTV
®
Series ventilator Page 10-19
p/n 10664, Rev. Y
PIP LED
Use the PIP LED option to turn the display of the PIP LED on the airway display on or off. When the
PIP LED is on, the airway pressure display LED representing the Peak Inspiratory Pressure of the
previous breath remains lit during exhalation.
To modify the PIP LED Setting:
1) Push the Select button while PIP LED is displayed.
2) PIP LED ON or PIP LED OFF is displayed.
3) Turn the Set Value knob until the desired setting is displayed.
4) Push the Select button.
Options: ON or OFF
Model Number / Serial Number
Use the Model Number / Serial Number option to view the LTV’s model or serial number, and to verify
LTM Graphics Monitor compatibility.
To view the LTV model number:
1) Turn the Set Value knob while in the VENT OP menu until LTV xxxx is displayed.
• The model number is displayed as: LTV xxxx where xxxx is the model of the ventilator.
• The model number is set when the ventilator is manufactured.
2) Push the Control Lock button to exit, or the Select button to display the serial number option.
To view the LTV serial number:
1) Push the Select button when the LTV model number (LTV xxxx) is displayed.
• The serial number is displayed on the left side of the display area as: xxxxxx where xxxxxx
is the serial number of the ventilator.
• The serial number is set when the ventilator is manufactured.
2) Push the Control Lock button or the Select button to return to the model number option.
To verify LTM Graphics Monitor Compatibility:
1) Push the Select button when the LTV Model Number (LTV xxxx) is displayed.
• The message LTM will be displayed on the right side of the display area if the ventilator was
originally manufactured or upgraded by Pulmonetic Systems to accommodate the LTM
Graphics Monitor.
2) Push the Control Lock button or the Select button to return to the model number option.
