Page C-6 LTV
®
Series ventilator Operator’s Manual
p/n 10664, Rev. Y
Protective Boot Installation
Supplies/Tools Required:
Item c, Protective Boot, Upper (1) P/N 11421
Item d, Protective Boot, Lower (1) P/N 11420
Replacement Screws Kit, P/N 11149
Torque wrench (20 in-oz / 0.14 Nm to 60 in-oz / 0.42 Nm range)
Phillips-head screwdriver
To Install the Upper Protective Boot
86
:
1) Carefully place and support the disconnected ventilator in an upright position on a clean, dry
surface.
2) Using a Phillips-head screwdriver, remove the two upper back panel pan-head and two side
panel flat-head mounting screws indicated in the illustration.
Do not remove the mating finish washers.
3) Orient the upper protective boot (c) over the ventilator as shown in the illustration (next page).
Move the boot down into position on the top of the ventilator and align its four screw holes with
the corresponding holes in the ventilator back and side panels.
4) Insert and thread two #4-40 flat-head mounting screws with finish washers h through the screw
holes in the legs of the upper boot, as indicated in the illustration (next page).
WARNING
Specific Boot Installation Screw Location - One leg of the upper protective boot has an additional
screw hole (furthest from the end of the leg);
On earlier version ventilators, the screw hole will align with the upper hole in the boot and
requires the use of the 1/4” mounting screw.
On current version ventilators, the screw hole will align with the lower hole in the boot and
requires the use of the 3/8” mounting screw.
AVERTISSEMENT
Emplacement des vis d’installation d’un gaine spécifique – Une patte de la gaine protectrice
supérieure possède un trou de vis supplémentaire (le plus éloigné de l’extrémité de la patte);
Sur les anciennes versions des ventilateurs, le trou de la vis s’alignera au trou supérieur de la
gaine et vous devez utiliser une vis de montage de 1/4".
Sur la version actuelle des ventilateurs, le trou de la vis s’alignera au trou inférieur de la gaine et
vous devez utiliser une vis de montage de 3/8”.
86
Refer to page C-9 for information concerning the appropriate accessories mounting screws or accessories
replacement screws location, type and length to use when removing or exchanging external accessories on
an LTV® Series ventilator.
