Page 10-6 LTV
®
Series ventilator Operator’s Manual
p/n 10664, Rev. Y
Patient Assist
Use the PNT ASSIST menu item to configure the Patient Assist port output signal to be generated for
use with remote alarm systems.
• Allows for the changing of the patient assist alarm output signal used with remote alarm
systems, which in turn will allow users a means of distinguishing the high pressure alarm
(HIGH PRES) from other alarms.
To select the Patient Assist output signal:
1) Push the Select button while PNT ASSIST is displayed.
2) NORMAL or PULSE is displayed.
• When NORMAL is selected, the ventilator sets the Patient Assist Port output signal
continuously on for all alarms and is for use with single tone remote alarm and patient assist
call systems. NORMAL is the factory set default setting.
• When PULSE is selected, the ventilator sets the Patient Assist Port output signal continuous
on for the HIGH PRES alarm, cycles the Patient Assist output signal on / off for all other
alarms and is for use with dual tone remote alarm systems.
3) Turn the Set Value knob until the desired setting is displayed.
4) Push the Select button.
Range: PULSE or NORMAL
Exit
To return to the top of the ALARM OP menu:
1) Push the Select button while EXIT is displayed.
