Operator’s Manual LTV
®
Series ventilator Page 11-5
p/n 10664, Rev. Y
Display Test (cont)
Verify displays are illuminated in the following colors:
Display Color Display Color
Airway Pressure Display Green Pressure Mode LED
54
Green
Display Window Red Assist/Control Mode LED Green
Breath Rate Green SIMV/CPAP Mode LED Green
Tidal Volume Green NPPV Mode LED Green
Pressure Control
54
Green Inspiratory / Expiratory
55
Green
Inspiratory Time Green Manual Breath LED Green
Pressure Support Green Low Pressure O
2
Source LED
55
Green
O
2
% (O
2
Flush)
55
Green Control Lock LED Green
Sensitivity Green Patient Effort LED Green
High Pressure Limit Alarm Red External Power LED Not tested
Low Pressure Alarm Red Charge Status LED Not tested
Low Minute Volume Alarm Red Battery Level LED Amber
On/Standby LED Green Vent Inop LED Not tested
Volume Mode LED
54
Green Silence Reset LED Red
3) To end the display test, push the Select button again and the next menu item is displayed.
If the Display Test fails, see Chapter 15 - Troubleshooting for more information.
54
Not applicable to the LTV
®
900.
55
Not applicable to the LTV
®
900 and 950.
