Operator’s Manual LTV
®
Series ventilator Page C-19
p/n 10664, Rev. Y
Ventilator Settings and Procedure Performance Requirement
G) Disconnect the high pressure sense
line from the ventilator
(see the illustration in Appendix C -
Patient Breathing Circuit –
Connection Instructions)
• DISC/SENSE alarm activates on the next
breath
H) Reconnect the high pressure sense
line and clear the alarm
I) Change control settings as follows:
Mode: Pressure, Assist/Cntl
Pressure Control: 40
PEEP: Max
(LTV
®
950 / 1000 Only)
Selected Monitors should read as follows:
• PIP: 36 to 44 cmH2O
• PEEP: 17 to 23 cmH2O
• No alarms activate
J) Disconnect AC Adapter from
Ventilator at pigtail cable connector
• POWER LOST alarm activates
• Battery Level LED illuminates showing the
charge level
• Ventilator continues to operate from the
internal battery
