Q2 Q2A - Page 183

Standards Compliance
5
5.2 European Standards
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 183
Three-Phase 400 V Class
Model Terminals
Recommended
Gauge
mm
2
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
mm
2
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
N∙m (lb.∙in.)
Size Shape
4002
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
4004
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
4005
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
4007
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
4009
R/L1, S/L2, T/L3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 2.5
2.5 - 16
(2.5 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 2.5
2.5 - 4
(2.5 - 4)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
2.5
*4
2.5 - 10
(-)
- M4 Phillips/slotted combo
1.2 - 1.5
(10.6 - 13.3)
