Q2 Q2A User Manual

5.3 UL Standards
214 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Drive Model
Maximum Applicable Motor Output
kW (HP)
Input Current Rating
A
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
2030 5.5 (7.5) 30 FWH-125B
2042 7.5 (10) 40.3 FWH-150B
2056 11 (15) 58.2 FWH-200B
2070 15 (20) 78.4 FWH-225A
2082 18.5 (25) 96
FWH-225A
FWH-250A
*1
2110 22 (30) 82
FWH-225A
FWH-250A
*1
2138 30 (40) 111
FWH-275A
FWH-300A
*1
2169 37 (50) 136
FWH-275A
FWH-350A
*1
2211 45 (60) 164
FWH-325A
FWH-450A
*1
2257 55 (75) 200 FWH-600A
2313 75 (100) 271 FWH-800A
2360 90 (125) 324 FWH-1000A
2415 110 (150) 394 FWH-1000A
*1 A fuse with a large rated current for applications with repeated loads is recommended.
Table 5.15 Factory-Recommended Branch Circuit Protection: 400 V Class (ND)
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Input Voltage < 460 V
Maximum Applicable Motor
Output
kW (HP)
Input Voltage ≥ 460 V
Input Current Rating
A
Semiconductor Protection
Fuse Rated Current
Manufacturer: EATON/
Bussmann
4002 0.75 (1) 0.75 (1) 2.5 FWH-50B
4004 1.5 (2) 1.5 (2) 4.7 FWH-50B
4005 2.2 (3) 2.2 (3) 6.7 FWH-50B
4007 3.0 (4) 3.0 (4) 8.9 FWH-60B
4009 4.0 (5) 3.7 (5) 11.7 FWH-60B
4012 5.5 (7.5) 5.5 (7.5) 15.8 FWH-60B
4018 7.5 (10) 7.5 (10) 21.2 FWH-80B
4023 11 (15) 11 (15) 30.6 FWH-90B
4031 15 (20) 15 (20) 41.3 FWH-150B
4038 18.5 (25) 18.5 (25) 50.5 FWH-200B
4044 22 (30) 22 (30) 59.7 FWH-200B
4060 30 (40) 30 (40) 58.3 FWH-225A
4075 37 (50) 37 (50) 71.5 FWH-250A
4089 45 (60) 45 (60) 86.5 FWH-275A
4103 55 (75) 55 (75) 105 FWH-275A
4140 75 (100) 75 (100) 142 FWH-300A
4168 90 (125) 90 (125) 170
FWH-325A
FWH-400A
*1
4208 110 (150) 110 (150) 207 FWH-500A
4250 132 (175) 150 (200) 248 FWH-600A
4296 160 (200) 185 (250) 300 FWH-700A
4371 200 (250) 220 (300) 373 FWH-800A
4389 220 (300) 260 (350) 410 FWH-1000A
4453 250 (335) 300 (400) 465 FWH-1200A
