Troubleshooting
7
7.4 Faults
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 283
Code Name Causes Possible Solutions
Noise interference along the encoder cable Isolate the encoder cable from the drive output line or a different
source of electrical interference.
Note:
• The drive detects this error if motor rotation position moves during Zero Servo.
• Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
TiM Keypad Time Not Set
There is a battery in the keypad, but the date and
time are not set.
Set the date and time with the keypad.
Note:
• Do a Fault Reset to clear the fault.
• o4-24 [bAT Detection Selection] enables and disables TiM detection.
Code Name Causes Possible Solutions
UL3 Undertorque Detection 1
A fault occurred on the machine.
Example: There is a broken pulley belt.
Examine the machine and remove the cause of the fault.
The parameters are incorrect for the load. Adjust L6-02 [Trq Det1 Level] and L6-03 [Trq Det1 Time]
settings.
Note:
• The drive detects this error if the drive output current is less than the level set in L6-02 for longer than L6-03.
• Do a Fault Reset to clear the fault.
• If the drive detects this error, it will operate the motor as specified by the Stopping Method set in L6-01 [Trq Det1 Select].
Code Name Causes Possible Solutions
UL4 Undertorque Detection 2
A fault occurred on the machine.
Example: There is a broken pulley belt.
Examine the machine and remove the cause of the fault.
The parameters are incorrect for the load. Adjust L6-05 [Trq Det2 Level] and L6-06 [Trq Det2 Time]
settings.
Note:
• The drive detects this error if the drive output current is less than the level set in L6-05 for longer than L6-06.
• Do a Fault Reset to clear the fault.
• If the drive detects this error, it will operate the motor as specified by the Stopping Method set in L6-04 [Trq Det2 Select].
Code Name Causes Possible Solutions
UL5 Mechanical Weakening Detection 2
The drive detected undertorque as specified by the
conditions for mechanical weakening detection set
in L6-08 [MechF Enable].
Examine the machine for deterioration.
Note:
• Do a Fault Reset to clear the fault.
• If the drive detects this error, it will operate the motor as specified by the Stopping Method set in L6-08.
Code Name Causes Possible Solutions
Uv1 DC Bus Undervoltage
There is a phase loss in the drive input power. Correct errors with the wiring for main circuit drive input power.
There is loose wiring in the drive input power
terminals.
Tighten the terminal screws to the correct tightening torque.
The drive input power voltage is changing too
much.
• Examine the input power for problems.
• Make the drive input power stable.
• If the input power supply is good, examine the magnetic
contactor on the main circuit side for problems.
There was a loss of power. Use a better power supply.
The main circuit capacitors have become
unserviceable.
Examine the capacitor maintenance time in monitor U4-05
[Capacitor Maintenance]. If U4-05 is more than 90%, replace the
control board or the drive. For information about replacing the
control board, contact the manufacturer or your nearest sales
representative.
The relay or contactor on the soft-charge bypass
relay is damaged.
U4-06 [SoftChgRelay Maint] shows the performance life of the
soft-charge bypass relay. If U4-06 is more than 90%, replace the
board or the drive. For information about replacing the control
board, contact the manufacturer or your nearest sales
representative.
Note:
• The drive detects this error if the DC bus voltage decreases below the level set in L2-05 [UV Detection Lvl (Uv1)] while the drive is running.
• The Uv1 detection level is approximately 190 V for a 200 V class drives. The detection level is approximately 380 V for 400 V class drives. The detection level is
approximately 350 V when E1-01 [Input AC Supply Voltage] < 400.
• Do a Fault Reset to clear the fault.
• Fault trace is not available for this fault.
• L5-08 [U/OV,OH,GF A-Reset Select] disables the Auto Restart function.
