Specifications
10
10.3 Model Specifications (400 V Class)
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 369
Table 10.7 Rating (400 V Class)
Model
Input
Voltage
Duty Rating 4140 4168 4208 4250 4296 4371 4389
Maximum Applicable Motor
Output (kW)
< 460 V
*1
HD 55 75 90 110 132 160 200
ND 75 90 110 132 160 200 220
≧ 460 V
*2
HD 55 75 90 110 150 185 220
ND 75 90 110 150 185 220 260
Maximum Applicable Motor
Output (HP)
< 460 V
*1
HD 75 100 125 150 175 200 250
ND 100 125 150 175 200 250 300
≧ 460 V
*2
HD 75 100 125 150 200 250 300
ND 100 125 150 200 250 300 350
Input
Rated Input
Current
*3
(A)
< 460 V
HD (AC) 105 142 170 207 248 300 373
HD (DC) 129 174 209 254 304 367 457
ND (AC) 142 170 207 248 300 373 410
ND (DC) 174 209 254 304 367 457 502
≥ 460 V
HD (AC) 86.9 118 141 171 232 289 346
HD (DC) 107 144 172 210 284 354 424
ND (AC) 118 141 171 232 289 346 403
ND (DC) 144 172 210 284 354 424 494
Outputs
Rated Output
Capacity
(kVA)
< 460 V
*4
HD 74 99 118 142 171 200 244
ND 92 111 137 165 195 244 256
≧ 460 V
*5
HD 76 99 124 143 191 241 288
ND 99 124 143 191 241 288 330
Rated Output
Current (A)
< 460 V
HD 112 150 180 216 260 304 371
ND 140 168 208 250 296 371 389
≥ 460 V
HD 96 124 156 180 240 302 361
ND 124 156 180 240 302 361 414
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds
• ND: 110% of the rated output current for 60 seconds
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 5 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 10 kHz maximum.
Maximum Output Voltage
Three-phase 380 V to 480 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• Advanced Open Loop Vector Control (AOLV) and EZ Open Loop Vector Control (EZOLV): 120 Hz
• Closed Loop V/f Control (CL-V/f), Closed Loop Vector Control (CLV), Advanced Open Loop Vector
Control for PM (AOLV/PM), and Closed Loop Vector Control for PM (CLV/PM): 400 Hz
• V/f Control (V/f), Open Loop Vector Control (OLV), and Open Loop Vector Control for PM (OLV/PM): 590
Hz
Measures for
Harmonics
DC Reactor Standard internal characteristics
Braking
Device
Braking Transistor
Standard internal
characteristics
External options
EMC Filter
EMC Filter
IEC61800-3, C3
There is a category C3 EMC filter in the drive.
