10.3 Model Specifications (400 V Class)
370 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Model
Input
Voltage
Duty Rating 4140 4168 4208 4250 4296 4371 4389
Power Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 380 V to 480 V at 50/60 Hz
• DC power supply 513 V to 679 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
< 460 V
HD 84 113 136 165 198 239 297
ND 113 136 165 198 239 297 327
≥ 460 V
HD 72 98 117 142 193 240 288
ND 120 143 174 236 295 352 410
*1 The maximum applicable motor output complies with 380 V motor ratings as specified in Annex G of IEC 60947-4-1. The rated
output current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 460 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*3 Assumes the value at the rated output current. The input current rating changes when the power supply transformer, input reactor,
wiring connections, or power supply impedance change.
*4 The rated output capacity is calculated with a rated output voltage of 380 V.
*5 The rated output capacity is calculated with a rated output voltage of 460 V.
Table 10.8 Rating (400 V Class)
Model Input Voltage Duty Rating 4453 4568 4675
Maximum Applicable Motor Output (kW)
< 460 V
*1
HD 220 250 315
ND 250 315 355
≧ 460 V
*2
HD 260 300 335
ND 300 335 370
Maximum Applicable Motor Output (HP)
< 460 V
*1
HD 300 335 400
ND 335 400 450
≧ 460 V
*2
HD 350 400 450
ND 400 450 500
Input
Rated Input Current
*3
(A)
< 460 V
HD (AC) 410 465 584
HD (DC) 502 569 715
ND (AC) 465 584 657
ND (DC) 569 715 805
≥ 460 V
HD (AC) 403 460 516
HD (DC) 494 563 632
ND (AC) 460 516 573
ND (DC) 563 632 702
To Next Page
