Q2 Q2A User Manual

10.8 Drive Exterior and Mounting Dimensions
386 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2 H1 H2 t1 t2 d
4007
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.7
(8.16)
4009
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.7
(8.16)
4012
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
3.7
(8.16)
4018
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
4.0
(8.82)
4023
140
(5.51)
260
(10.24)
211
(8.31)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
248
(9.76)
6
(0.236)
1.6
(0.063)
5
(0.197)
M5
4.0
(8.82)
