Q2 Q2A - Page 389

Specifications
10
10.8 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 389
■ 2110, 4075
Figure 10.4 Exterior and Mounting Dimensions Diagram for 2110, 4075
Table 10.31 200 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H4 t1 t2 d
2110
240
(9.45)
400
(15.75)
280
(11.02)
166
(6.54)
114
(4.49)
195
(7.68)
186
(7.32)
12
(0.472)
375
(14.76)
17.5
(0.689)
17.5
(0.689)
2.3
(0.091)
2.3
(0.091)
M6
19
(41.90)
Table 10.32 400 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H4 t1 t2 d
4075
240
(9.45)
400
(15.75)
280
(11.02)
166
(6.54)
114
(4.49)
195
(7.68)
186
(7.32)
12
(0.472)
375
(14.76)
17.5
(0.689)
17.5
(0.689)
2.3
(0.091)
2.3
(0.091)
M6
15
(33.08)
