Q2 Q2A User Manual

10.8 Drive Exterior and Mounting Dimensions
394 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ 4453 to 4675
Figure 10.9 Exterior and Mounting Dimensions Diagram for 4453 to 4675
Table 10.41 400 V class (IP20)
Model
Dimensions mm (in.)
Weigh
t
kg
(lb.)
W H D D1 D2 W1 W2 W3 W4
W5
(max.)
H1 H2 H3 H4 t1 t2 d
4453
510
(20.08)
1140
(44.88)
480
(18.90)
260
(10.24)
220
(8.66)
450
(17.72)
450
(17.72)
225
(8.86)
225
(8.86)
20
(0.787)
1093
(43.03)
25.5
(1.00)
43.5
(1.71)
30.5
(1.20)
4.5
(0.177)
4.5
(0.177)
M12
198
(436.59
)
4568
510
(20.08)
1140
(44.88)
480
(18.90)
260
(10.24)
220
(8.66)
450
(17.72)
450
(17.72)
225
(8.86)
225
(8.86)
20
(0.787)
1093
(43.03)
25.5
(1.00)
43.5
(1.71)
30.5
(1.20)
4.5
(0.177)
4.5
(0.177)
M12
198
(436.59
)
4675
510
(20.08)
1140
(44.88)
480
(18.90)
260
(10.24)
220
(8.66)
450
(17.72)
450
(17.72)
225
(8.86)
225
(8.86)
20
(0.787)
1093
(43.03)
25.5
(1.00)
43.5
(1.71)
30.5
(1.20)
4.5
(0.177)
4.5
(0.177)
M12
207
(456.44
)
