Specifications
10
10.8 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 393
■ 2360, 2415, 4371, 4389
Figure 10.8 Exterior and Mounting Dimensions Diagram for 2360, 2415, 4371, 4389
Table 10.39 200 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
2360
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.787)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.177)
4.5
(0.177)
M12
106
(233.73)
2415
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.787)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.177)
4.5
(0.177)
M12
112
(246.96)
Table 10.40 400 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
4371
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.787)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.177)
4.5
(0.177)
M12
111
(244.76)
4389
440
(17.32)
800
(31.50)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
20
(0.787)
757
(29.80)
28
(1.10)
44
(1.73)
30
(1.18)
4.5
(0.177)
4.5
(0.177)
M12
117
(257.99)
