10.8 Drive Exterior and Mounting Dimensions
392 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ 2257, 2313, 4208 to 4296
Figure 10.7 Exterior and Mounting Dimensions Diagram for 2257, 2313, 4208 to 4296
Table 10.37 200 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
2257
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
59
(130.10)
2313
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
61
(134.51)
Table 10.38 400 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
4208
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
61
(134.51)
4250
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
63
(138.92)
4296
312
(12.28)
700
(27.56)
420
(16.54)
260
(10.24)
160
(6.30)
218
(8.58)
218
(8.58)
18
(0.709)
659
(25.94)
28
(1.10)
43.5
(1.71)
28.5
(1.12)
4.5
(0.177)
4.5
(0.177)
M10
66
(145.53)
