Specifications
10
10.8 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 391
■ 2169, 2211, 4140, 4168
Figure 10.6 Exterior and Mounting Dimensions Diagram for 2169, 2211, 4140, 4168
Table 10.35 200 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
2169
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.472)
516
(20.31)
17.5
(0.689)
28.5
(1.12)
20.5
(0.807)
2.3
(0.091)
2.3
(0.091)
M8
35
(77.18)
2211
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.472)
516
(20.31)
17.5
(0.689)
28.5
(1.12)
20.5
(0.807)
2.3
(0.091)
2.3
(0.091)
M8
36
(79.38)
Table 10.36 400 V class (IP20)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W5
(max.)
H1 H2 H3 H4 t1 t2 d
4140
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.472)
516
(20.31)
17.5
(0.689)
28.5
(1.12)
20.5
(0.807)
2.3
(0.091)
2.3
(0.091)
M8
37
(81.59)
4168
264
(10.39)
543
(21.38)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
12
(0.472)
516
(20.31)
17.5
(0.689)
28.5
(1.12)
20.5
(0.807)
2.3
(0.091)
2.3
(0.091)
M8
38
(83.79)
