10.8 Drive Exterior and Mounting Dimensions
398 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ 4075
Figure 10.13 Exterior and Mounting Dimensions Diagram 4
Table 10.45 400 V Class (UL Type 1)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W3
(max.)
H0 H1 H2 H3 H5 t1 t2 d
4075
244
(9.61)
500
(19.69)
280
(11.02)
166
(6.54)
114
(4.49)
195
(7.68)
186
(7.32)
10
(0.394)
400
(15.75)
375
(14.76)
17.5
(0.689)
100
(3.94)
17.5
(0.689)
2.3
(0.091)
2.3
(0.091)
M6
18
(39.69)
