Q2 Q2A - Page 399

Specifications
10
10.8 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 399
■ 4089, 4103
Figure 10.14 Exterior and Mounting Dimensions Diagram 5
Table 10.46 400 V Class (UL Type 1)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W3
(max.)
H0 H1 H2 H3 H5 t1 t2 d
4089
259
(10.20)
580
(22.83)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
10
(0.394)
450
(17.72)
424
(16.69)
16
(0.630)
130
(5.12)
21
(0.827)
2.3
(0.091)
2.3
(0.091)
M6
24
(52.92)
4103
259
(10.20)
580
(22.83)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
10
(0.394)
450
(17.72)
424
(16.69)
16
(0.630)
130
(5.12)
21
(0.827)
2.3
(0.091)
2.3
(0.091)
M6
29
(63.95)
