Parameter List
11
11.8 H: TERMINALS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 457
Setting Function Description Ref.
15 FreqDetect 3
The terminal deactivates when the output frequency is higher than the setting value of “L4-03 [SpAgree Det.Level
(+/-)] + L4-04 [SpAgree Det.Width(+/-)]”. After the terminal deactivates, the terminal stays off until the output
frequency is at the value of L4-03.
Note:
• The detection level set with L4-03 is a signed value. The drive will only detect in one direction.
• The drive uses the motor speed as the reference in CLVand CLV/PM.
ON : The output frequency is less than the value of L4-03 or is not higher than the value of L4-03 + L4-04.
OFF : The output frequency is higher than the value of L4-03 + L4-04.
724
16 FreqDetect 4
The terminal activates when the output frequency is higher than the value of L4-03 [SpAgree Det.Level(+/-)]. After
the terminal activates, the terminal stays on until the output frequency is at the value of L4-03 - L4-04.
ON : The output frequency is higher than the value of L4-03.
OFF : The output frequency is less than the value of “L4-03 - L4-04”, or it is not higher than the value of L4-03.
725
17 @Fast Stop
The terminal activates when the fast stop is in operation.
725
18 @KEBridethru
The activates during KEB Ride-Thru.
725
19 @ShortCBraking
The terminal activates during Short Circuit Braking.
Note:
When A1-02 = 8 [Control Method = EZ Vector], this function is available if you use a PM motor.
726
1A @BaseblockNO
The terminal turns on during baseblock. When the drive is in baseblock, the drive output transistor stops switching
and the drive will not make DC bus voltage.
ON : During baseblock
OFF : The drive is not in baseblock.
726
1B @BaseblockNC
The terminal deactivates during baseblock. When the drive is in baseblock, the drive output transistor stops
switching and does not make DC bus voltage.
ON : The drive is not in baseblock.
OFF : During baseblock
726
1C FreqRefSource
Shows the selected frequency reference source.
ON : The keypad is the frequency reference source.
OFF : b1-01 or b1-15 [Freq. Ref. Sel. 1 or Freq. Ref. Sel. 2] is the frequency reference source.
726
1D RunCmdSource
Shows the selected Run command source.
ON : The keypad is the Run command source.
OFF : b1-02 or b1-16 [Run Comm. Sel 1 or Run Comm. Sel 2] is the Run command source.
726
1E Motor2 Select
The terminal activates when motor 2 is selected.
ON : Motor 2 Selection
OFF : Motor 1 Selection
726
1F Restart Enable
The terminal activates when the Auto Restart function is trying to restart after a fault.
726
20 FltReset Active
The terminal turns on when the drive receives the Reset command from the control circuit terminal, serial
communications, or the communication option.
727
21 PolePos Detection
The terminal activates when drive receives a Run command and the drive detects the motor magnetic pole position
of the PM motor.
727
22 Ext 24V Supply
The terminal activates when there is an external 24V power supply between terminals E24V-A0V.
ON : An external 24V power supply supplies power.
OFF : An external 24V power supply does not supply power.
727
2F @SpeedSearch
The terminal activates when the drive is doing speed search.
727
30 @TorqueLimit
The terminal activates when the torque reference is the torque limit set with L7 parameters, H3-02 [AI1 Function
Selection], H3-06 [AI3 Function Selection], or H3-10 [AI2 Function Selection].
727
31 @SpdLim@Trq
The motor accelerates in the forward direction or the reverse direction after enabling torque control and the
externally input torque reference is disproportionate to the load. The output terminal activates when this speed is
not higher than a constant speed and the motor speed is at the speed limit. This does not include operation when the
drive is stopped.
727
