Parameter List
11
11.19 Defaults by Drive Model and Duty Rating ND/HD
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 513
Parameter Unit
Drive Model
4371 4389 4453 4568
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 160 200 200 220 220 250 250 315
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 0.029 0.025 0.025 0.02 0.02 0.014 0.014 0.014
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 20 20 20 20 20 20 20 20
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 2850 3200 3200 3700 3700 4700 4700 4700
E5-01 PM Mot Code Selection - 124A 124A 124A 124A 124A 124A 124A 124A
L2-02 RideThrough Time@Power Loss s 2 2 2 2 2 2 2 2
L2-03 Min Baseblck Time s 1.8 1.9 1.9 2 2 2.1 2.1 2.1
L2-04 Powloss Ramp Time@recovery s 1 1 1.8 1.8 1.8 2 2 2
L2-05 UV Detection Lvl (Uv1) - 380 380 380 380 380 380 380 380
L3-24 Acc@Rated Torque s 0.777 0.864 0.864 0.91 0.91 1.392 1.392 1.392
L8-02 Overheat Alm Level °C 130 130 140 140 140 140 140 140
L8-09 Ground Fault Selection - 1 1 1 1 1 1 1 1
L8-38 Carrier Reduction Mode - 2 2 2 2 2 2 2 2
n1-01 HuntPrev Selection - 2 2 2 2 2 2 2 2
n1-03 HuntPrev Time Constant ms 30 30 100 100 100 100 100 100
n1-16 HuntPrev HiFc Gain - 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 0.777 0.864 0.864 0.91 0.91 1.392 1.392 1.392
n8-11 Observ.Calc Gain2 - 50.0 50.0 50.0 50.0 50.0 50.0 50.0 50.0
Parameter Unit
Drive Model
4675
C6-01 ND/HD Duty Selection -
HD ND
0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 315 355
b3-04 SpSrch V/F Gain % 60 60
b3-06 Speed Curr Lev1 for
Estimation
- 0.7 0.7
b3-08 Speed ACR PGain for
Estimation
- 0.8 0.8
b3-26 Dir. Determ. Level - 1000 1000
b8-03 eSave Filter Time s 2.00 2.00
b8-04 eSave Coef. Value - 21.76 23.84
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
11.00 12.00
C6-02 Carrier Frequency Selection - 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 500 650
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 1.25 1
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 130 130
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 0.014 0.012
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 20 20
