11.19 Defaults by Drive Model and Duty Rating ND/HD
514 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Parameter Unit
Drive Model
4675
C6-01 ND/HD Duty Selection -
HD ND
0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 315 355
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 4700 5560
E5-01 PM Mot Code Selection - FFFF FFFF
L2-02 RideThrough Time@Power
Loss
s 2 2
L2-03 Min Baseblck Time s 2.1 2.3
L2-04 Powloss Ramp
Time@recovery
s 2 2.2
L2-05 UV Detection Lvl (Uv1) - 380 380
L3-24 Acc@Rated Torque s 1.392 1.667
L8-02 Overheat Alm Level °C 140 140
L8-09 Ground Fault Selection - 1 1
L8-38 Carrier Reduction Mode - 2 2
n1-01 HuntPrev Selection - 2 2
n1-03 HuntPrev Time Constant ms 100 100
n1-16 HuntPrev HiFc Gain - 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 1.392 1.667
n8-11 Observ.Calc Gain2 - 50.0 50.0
