12.7 H: TERMINALS
690 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
When the setting value is 0, the function is disabled.
■ H1-25 DI5 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-25
(0B74)
DI5 Funct.Sel 2
Sets the second function for MFDI terminal DI5.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI5 activates, it will operate the function set to H1-05 [DI5 Function Selection] and the
function set to H1-25 at the same time.
When the setting value is 0, the function is disabled.
■ H1-26 DI6 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-26
(0B75)
DI6 Funct.Sel 2
Sets the second function for MFDI terminal DI6.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI6 activates, it will operate the function set to H1-06 [DI6 Function Selection] and the
function set to H1-26 at the same time.
When the setting value is 0, the function is disabled.
■ H1-27 DI7 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-27
(0B76)
DI7 Funct.Sel 2
Sets the second function for MFDI terminal DI7.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI7 activates, it will operate the function set to H1-07 [DI7 Function Selection] and the
function set to H1-27 at the same time.
When the setting value is 0, the function is disabled.
■ H1-28 DI8 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-28
(0B77)
DI8 Funct.Sel 2
Sets the second function for MFDI terminal DI8.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI8 activates, it will operate the function set to H1-08 [DI8 Function Selection] and the
unction set to H1-28 at the same time.
When the setting value is 0, the function is disabled.
■ Modbus MFDI 1 to 3 Function Selection
You can set the function for the MFDI to Modbus register bit 0 to 2 of [15C0(Hex.)]. Use H1-40 to H1-42 [Mbus
15C0h b0 Input Function to Mbus 15C0h b2 Input Function] to select the function.
Note:
• Refer to H1-xx “MFDI setting values” for the setting values of the MFDI.
• You cannot set 5 [3-Wire Seq.] or 20 to 2F [External fault] in H1-40 to H1-42.
• When you will not use H1-40 to H1-42, set them to 0 [Through Mode].
• You cannot use MFDI for digital input option D1-A3 at the same time as function selection for Modbus MFDI 1 to 3.
■ H1-40 Mbus 15C0h b0 Input Function
No.
(Hex.)
Name Description
Default
(Range)
H1-40
(0B54)
Mbus 15C0h b0 Input
Function
Sets the MFDI function for bit 0 of Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
