Parameter Details
12
12.7 H: TERMINALS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 689
Note:
The default setting is A when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-07 DI7 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-07
(0404)
DI7 Function Selection
Sets the function for MFDI terminal DI7.
6
(0 - 19F)
Note:
The default setting is B when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-08 DI8 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-08
(0405)
DI8 Function Selection
Sets the function for MFDI terminal DI8.
Note:
The default setting is 6 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
1B
(0 - 19F)
Note:
The default setting is 6 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-21 DI1 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-21
(0B70)
DI1 Funct.Sel 2
Sets the second function for MFDI terminal DI1.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI1 activates, it will operate the function set to H1-01 [DI1 Function Selection] and the
function set to H1-21 at the same time.
When the setting value is 0, the function is disabled.
■ H1-22 DI2 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-22
(0B71)
DI2 Funct.Sel 2
Sets the second function for MFDI terminal DI2.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI2 activates, it will operate the function set to H1-02 [DI2 Function Selection] and the
function set to H1-22 at the same time.
When the setting value is 0, the function is disabled.
■ H1-23 DI3 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-23
(0B72)
DI3 Funct.Sel 2
Sets the second function for MFDI terminal DI3.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI3 activates, it will operate the function set to H1-03 [DI3 Function Selection] and the
function set to H1-23 at the same time.
When the setting value is 0, the function is disabled.
■ H1-24 DI4 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-24
(0B73)
DI4 Funct.Sel 2
Sets the second function for MFDI terminal DI4.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI4 activates, it will operate the function set to H1-04 [DI4 Function Selection] and the
function set to H1-24 at the same time.
