12.7 H: TERMINALS
688 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Setting Function
66 Dw2 Command
67 SpdSrch Fmax
68 SpdSrch Fref
6A PID Disable
71 PID I Reset
72 PID I Hold
75 PID SS Cancel
76 PID InLv Select
77 PID SP 1
Setting Function
78 PID SP 2
7A PID BiDir
7B Fault Reset
7C Prg Lock
7D Drive OH2
7E Node Setup
7F Comms Test
90 to 97
*1
Q2pack DI1 to 10
9F Q2pack Disable
*1 Inverse input is not available.
■ H1-01 DI1 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-01
(0438)
DI1 Function Selection
Sets the function for MFDI terminal DI1.
1
(1 - 4, 6 - 19F)
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-02 DI2 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-02
(0439)
DI2 Function Selection
Sets the function for MFDI terminal DI2.
2
(1 - 4, 6 - 19F)
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-03 DI3 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-03
(0400)
DI3 Function Selection
Sets the function for MFDI terminal DI3.
24
(0 - 19F)
■ H1-04 DI4 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-04
(0401)
DI4 Function Selection
Sets the function for MFDI terminal DI4.
7B
(0 - 19F)
■ H1-05 DI5 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-05
(0402)
DI5 Function Selection
Sets the function for MFDI terminal DI5.
A
(0 - 19F)
Note:
The default setting is 5 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-06 DI6 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-06
(0403)
DI6 Function Selection
Sets the function for MFDI terminal DI6.
B
(0 - 19F)
