Mode Switch: The button at the right of “Mode Switch” is OFF, and the background color
of the select box is grey, indicating that the Engine cut function is turn off. The button at the right
of “Mode Switch” is ON, and the background color of the select box is blue, indicating that the
Engine cut function is turn on.
Switch select: PS1/PS2/PS3/PS4/PS5/Steering/Trigger can be set to turn on or turn off the
Engine cut function. Before setting the Engine cut
function switch, please check if the button you are ready
to select has occupied or not in the “Channel setting”
menu.
Preset point: the rudder amount when the engine
has cut. When pressing the Engine cut function switch
with the Engine cut function is turned on, the throttle
servo (motor) value is locked in the preset position and
does not operate even if the throttle trigger is operated.
If the servo was operated in the wrong setting, you may
lose control of the car/boat. The initial value of the
Preset point is 0%, 0% to 100% can be selected.
Status: indicates the throttle state when the engine has cut, “Ready” and “Trigger” can
be selected, controlled by the switch that set in “Switch select”. In the “Trigger” state, if the
Engine cut function is turned on, the throttle servo (motor) value is locked in the preset position
and does not operate even if the throttle trigger is operated.
Setting steps: turn on the RC8X, into home page, click the button at the left bottom of
