Setting steps: turn on your RC8X, click the button at the left bottom of RC8X into
System menu, click at the left of RC8X into
Information menu, click Battery, click the blue select box at
the right of Alarm voltage to change the alarm value, click
“-“ to reduce the number and click “+” to increase the
number. If you use a 2S LiPo battery to power for your RC8X,
then the alarm voltage number do not lower than
3.7V*2S=7.4V, 3S LiPo battery do not lower than 11.1V, 4S
LiPo battery do not lower than 14.8V.
Reset: click Reset will make the alarm voltage number back to 6.8V.
Back: click the button or short press the power button to return to the previous menu.
Attention: the other parameter setting steps in the Battery menu can follow: 2.1.5 Battery
(Transmitter Battery Voltage)
1.2.10 Compatible Receivers of RC8X
RC8X is packed with a R8FG receiver by default. RC8X is also compatible with 8 channels
receiver R8F capable of real-time transmission of RSSI, receiver, and model voltage. 7 channels
receiver R7FG, which with gyro integrated. 6 channels receiver R6FG, which with gyro integrated,
R6F with HV servo supported. 4 channels super micro receiver R4FGM with gyro integrated, R4F
with HV servo supported.
Note ： Since RadioLink radio control systems are not open sourced, that RadioLink
transmitters are ONLY compatible with RadioLink receivers and RadioLink receivers are ONLY
compatible with RadioLink transmitters.
