RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
131
2.8 SD Card Folder
Users can customize and change the content
of the files. For example, they can add or delete
firmware, modify the icon of the transmitter, and
modify the prompt sound.
…: click the … folder to back to the previous
directory, click all the folders under this menu to
enter the directory. Tap the mark “Previous” or
“Next” at the bottom of screen to switch the page.
2.8.1 SD Card Folder Name Introduction
Folder
Name
Function
Folder
Name
Function
Debug Info
Debug information
ESC
Icon of ESC
Firmware
Firmware of RC8X
Desktop
Icon of desktop
FONT
Font of RC8X
Cache file
Cache file
SIF
font library, the RC8X
will cannot power on if
delete the SIF folder
Battery
Cache file
Icon
All the Icons in RC8X
4WS
4 Wheel Steering
Signal
Icon of signal
Screenshot
Screenshot

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
