RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
72
2.3.8 Fail-safe
This function sets the servo operation position when transmitter signals cannot be received
by the receiver for some reason.
Setting steps: turn on the RC8X, into home page,
click the button at the left bottom of RC8X into
System menu, click into Basic menu, click the blue
select box named Fail-safe can into the menu to set the
fail-safe for channel 1 to channel 8. Click “-“ can
decrease the value, and click “+” can increase the
value, 0% to 100% can be selected.
The initial value is 0%, which means that when the
transmitter signals cannot be received by the receiver,
the throttle will stop to output, and the servo will keep
its position immediately before the reception was lost.
You can set the value to make the servo move to a preset position you want when the
fail-safe function is activated according to your cars or boats.
For gasoline engine cars, for safety, we recommend that this fail-safe function be used to set
the throttle channel in the direction in which the brakes are applied.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
