steering rate switch, please check if the button you are ready to select has occupied or not in the
“Channel setting” menu. Pull or push the DT3 will adjust the value of the steering rate.
Brake rate: The initial value of brake rate is 100%, 0% to 100% can be selected. Click “-“ ,
“+” or push the trimer button DT4 can adjust the brake effect.
Brake Rate Switch select: The initial switch of steering rate is DT4, DT1/DT2/DT3/DT4/DL1 can
be selected, select “NULL” indicate that this function is not enabled. Before select the brake
rate switch, please check if the button you are ready to select has occupied or not in the
“Channel setting” menu. Pull or push the DT4 will adjust the value of the brake rate.
2.3.13 Channel limiter
The channel limiter function is to limit the minimum and the maximum servo movement.
By superimposing mixing, the linkage can be
protected by setting the limiter in case servo motion
becomes unexpectedly large.
Different from steering rates and brake rates,
each channels’ left and right servo travel limits can
be adjusted separately.
Setting steps: turn on the RC8X, into home page,
click the button at the left bottom of RC8X into
System menu, click into Basic menu, click the
blue select box named Channel limiter can into the
menu to set the minimum and the maximum limit of
