RadioLink Electronic Limited
www.radiolink.com
Alarm type: the sound type for alarm, it defaults without any warning tone. But if you want to
the RC8X waning you to change the battery when the model battery voltage is lower than the
value you have set, there are voice broadcast and 20 types warning tone can be chosen.
Vibration type: it defaults “Inhibit”, Mode1, Mode2, and Mode3 can be selected.
Alarm voltage: the low model battery voltage alarm, it defaults 6.6V, the minimum voltage
can be set 6V, and the maximum voltage can be set 60V, the low model battery voltage has set
depends on the battery you use. Click “-“ to reduce the number and click “+” to increase the
number. If you use a 3S LiPo battery to power for your model, then the alarm voltage number do
not lower than 3.7V*3S=11.1V, 4S LiPo battery do not lower than 14.8V.
Alarm interval: the interval period for alarm, if the model battery voltage is lower than the
alarm voltage you have set, it defaults alarm once every 10 seconds, the alarm interval time can
be customized.
1.3.4 Signal Mode and Gyro Function of R8FG
R8FG support PWM, SBUS, and PPM signals output.
The signal mode and gyro function can be switched by press the bind button (ID SET),
setting steps as follow:
R8FG indicate LED introduction:
① Green LED always on indicates normal working mode.
② Green and red LEDs always on indicates gyro working mode.
Attention: If binding is not successful or loss the signal, the green LED will keep flashing to
notify.
