Trim switch: DT1/DT2/DT3/DT4/DL1 can be select to adjust the idle up rate, “NULL”:
indicate that no switch to adjust the idle up rate.
Function switch: PS1/PS2/PS3/PS4/PS5/Steering/Trigger can be selected to turn on or turn
off the idle up function, “NULL”: indicate that no switch selected.
Idle up rate: The initial value of idle up rate is 0%, -50% to 50% can be selected. If the idle up
status is ON, set the Idle up rate to 50% means the throttle neutral position is offset to the
forward side, and -50% means the throttle neutral position is offset to the brake side.
Attention:
1. Before setting the Trim switch, please check if the button you are ready to select has
occupied or not in the “Channel setting” menu.
For example: If you are ready to select the button DT1 as the Trim switch, you should check if
the DT1 have been set to control other function in the “Channel setting” menu first, if not, then
back to the “Idle up” menu to select the DT1 as the Trim switch, if have occupied, select
another switch to instead of the DT1 or select another switch as the Trim switch.
2. Before setting the Function switch, please check if the button you are ready to select has
occupied or not in the “Channel setting” menu. If not occupied, into “switch select” menu to
set the PS button as a “lock” button, then press it to turn on the idle up function, press it again
to turn off the idle up function.
2.3.12 D/R, ATL
D/R indicates the steering dual rate function.
