RadioLink Electronic Limited
www.radiolink.com
140
2.10.2 Remove the Wheel Installation Port Cover
1
Use the Phillips screwdriver to remove the two mounting screws (HA3.0*12mm screws)
on the left wheel installation port cover.
2
Gently pull off the left wheel installation port cover.
3
Gently pull out the USB port motherboard.
4
Remove the cable from the RC8X PCB board.
