RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
119
this function carefully so that the motors are not damaged.
Radiolink will not be responsible for motor controller, motor, and other vehicle trouble due
to the use of this function.
Setting steps: turn on the RC8X into home page, click the button at the left bottom of
RC8X into System menu, click into Mixing menu, click the blue select box named Dual ESC
mixing into the menu to set it.
2.6.6 CPS mixing
This function can set a switch (including steering wheel and throttle trigger) to trigger the
LED turn on or turn off. Channel 1 to channel 8 can be set as the trigger channel or operation.
If the CPS mixing function is on, and select the steering wheel or throttle trigger as the
trigger switch, then the LED will turn on, turn off, or blink when steering or push or pull the
trigger. The blink speed and trigger mode can be customized.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
