RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
42
according to actual needs.
2.1.10 Calibration
Wheel, trigger, and Rotary knob correction can be applied when a mechanical offset has
occurred for some reason.
Setting steps: turn on your RC8X, click the button
at the left bottom of RC8X into System menu, or click
the blue select box named Calibration to calibrate the
Wheel, Trigger, and Rotary knob.
Wheel: Steering adjustment
Tap “End point” of Wheel into steering calibration
menu, turn the steering wheel of the transmitter clockwise
to the end, and then counterclockwise to the end, then let
it back to neutral automatically, wait until the
minimum/neutral/maximum values are stopped to
change, and then click “Calibration finished”, then the
transmitter will automatically return to the “Calibration
menu” which means the steering calibration success.
Trigger: Throttle adjustment
Tap “End point” of Trigger into the throttle
calibration menu, pull the throttle trigger to full throttle
and the brake position, then let it go back to neutral
automatically, wait until the minimum/neutral/maximum values are stopped to change, and then

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
