Switch: PS1/PS2/PS3/PS4/PS5/Steering/Trigger can be set to turn on or turn off the Steering
brake function. Before setting the Steering brake function switch, please check if the button you
are ready to select has occupied or not in the “Channel setting” and “Switch select” menu.
Brake rate: is for the brake angle adjustment. The initial value is 0%, -120% to 120% can be
selected.
Setting steps: turn on the RC8X into home page, click the button at the left bottom of
RC8X into System menu, click into Mixing menu, click the blue select box named Steering
mixing into the menu to set it. Click “-“ to decrease the value and click “+” to increase the
value.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.
2.6.2 Brake mixing
This function is used when the front and rear brakes must be adjusted independently, for
example, in a 1/5 scale GP car. This mixing uses channel 2 to control the rear brakes and the
auxiliary channel or auxiliary channel servo to control the front brakes. Or, control channel 2 by
the independent throttle and control the rear and front brakes by the auxiliary channel. In
addition, mixing which varies the auxiliary channels brake rate in proportion to steering
operation is also possible.
Brake2/Brake3 button: The button under the “Brake1” or “Brake2” is OFF, and the
background color of the select box is grey, indicating that the Brake1/Brake2 mixing function is
turn off. The button under the “Brake1” or “Brake2” is ON, and the background color of the
