2.3.7 End point (EPA)
Use this function when performing left and right steering angle adjustments, throttle high
side/brake side operation amount adjustment, and
channel 3, 4, 5, 6, 7, 8 servo upside/down side operation
amount adjustment.
Correct the maximum steering angle of the left and
the right steering angles when there is a difference in the
turning radius due to the characteristics of the vehicle.
The left and right sides of each channel can be
adjusted independently, the default end point is 100, 0
to 120 can be selected.
Setting steps: turn on the RC8X, into home page,
click the button at the left bottom of RC8X into
System menu, click into Basic menu, click the blue select box named End point can into the
menu to adjust the end point for channel 1 to channel 8. Click “-“ can decrease the value, and
click “+” can increase the value.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
