2.3.6 Sub trim
Use this function to adjust the neutral position or the
entire range of the servo in the set direction of the
steering, throttle, channel 3, 4, 5, 6, 7, and 8 servos. The
sub trim of each channel is default 0%, -200% to 200% can
be selected.
Setting steps: turn on the RC8X, into home page, click
the button at the left bottom of RC8X into System
menu, click into Basic menu, click the blue select
box named Sub trim can into the menu to adjust the
neutral position or the entire range of the servo in the set
direction for channel 1 to channel 8. Click “-“ can decrease the value, and click “+” can
increase the value.
The direction of the steering, throttle, or switch’s operation corresponding to positive and
negative values is opposite if the channel set normal (set in Channel reverse menu). After set the
sub trim, the neutral position will move to the left/right by a certain percentage. For example: If
set the sub trim of Channel 1 as -30%, and the Channel 1 is set normal in Channel reverse menu,
then the neutral position of the Channel 1 will move 18 steps to the right.
Reset: click Reset will make the value back to the default number.
Back: click the button or short press the power button to return to the previous menu.
