RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
139
2.10 Modifying for Left-hand Use
The wheel section left and right installation direction can be reversed.
The wheel is default at the right of RC8X, users can reinstall it by a Phillips screwdriver.
The following operation takes the right-hand use modify to the left-hand use as an example:
2.10.1 Remove the Wheel
1
Use a Phillips screwdriver to remove the two mounting screws (HA3.0*12mm screws) on
the steering wheel adapter.
2
Gently pull off the steering wheel and do not pull the cable excessively. Since the
steering wheel has been locked by the plastic sheet, please do not pull it out directly.
3
Remove the three cables from the PCB board of RC8X, press the socket on the RC8X
4
Pull out the plastic plate under the wheel.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
