Trim mode: The button at the right of “Trim mode” is OFF, and the background color of the
select box is grey, indicating that the trim of the channel2 is not mixed. The button at the right of
“Trim mode” is ON, and the background color of the select box is blue, indicating that the trim
of the channel2 is mixed. When the steering or throttle channel is the master channel, trim data
can be added.
Mixing channel: is for set the master and slave channel.
Master: channel that applies to mix. Channel 1 to channel 8 can be selected as the master
channel.
Slave: channel 1 to channel 8 can be selected as the slave channel. The movement of the
master channel side will include the movement of the slave channel side.
Click 2/2 at the top right corner to back to the first programmable mixing setting page from
the second programmable mixing setting page.
Setting steps: turn on the RC8X into home page, click the button at the left bottom of
RC8X into System menu, click into Mixing menu, click the blue select box named
Programmable mixing into the menu to set it.
2.6.9 Tilt mixing
Tilt mixing uses an outboard engine and applies bidirectional mixing from rudder to flap and
from flap to rudder so that with a boat, rudder operation and tilt mixing operation can be
performed 2 servos.
Tilt mixing can be performed by rudder operation, by steering wheel and flap channel.
Mixing: The button at the right of “Mixing” is OFF, and the background color of the select
