box is grey, indicating that the Tilt mixing function is turn off. The button at the right of “Mixing”
is ON, and the background color of the select box is blue, indicating that the Tilt mixing function
is turn on.
CH1: channel 1 to channel 8 can be selected to control the tilt steering.
CH2: channel 1 to channel 8 can be selected to control the tilt flap.
CH1 rate/CH2 rate: for the mixing amount rate. The
initial value is 100%, -120% to 120% can be selected.
Both CH1 and CH2 rate set positive or negative value,
the tilt steering and tilt flap will keep move the same
direction, while if the CH1 rate set the positive value and
the CH2 rate set the negative value, the tilt steering and
tilt flap will move the opposite direction.
Flap: flap rate check and adjustment. The initial
value is 0%, -100% to 100% can be selected. The flap
value set depends on the angle of the two flap (steering
and flap). If you want to set the steering and flap
separately, please set the value of Rudder to flap or Flap to rudder.
Rudder to flap: Rudder to Flap mixing amount can be adjusted individually. The initial value
is 100%, -100% to 100% can be selected. -1% to -100% indicate the operate in same direction as
steering. 0% to 100% indicate the opposite direction of steering.
Flap to rudder: Flap to Rudder mixing amount can be adjusted individually. The initial value
is -100%, -100% to 100% can be selected. 0% to 100% indicate the operate in same direction as
