RadioLink RC8X User Manual

RadioLink Electronic Limited
www.radiolink.com
73
2.3.9 Acceleration
Neutral: This function is design for adjust the acceleration of throttle when it at the neutral
position. Using this function can improve the starting
performance of the gasoline engine cars by
increasing the neutral speed when the car engine
starts. The initial value of Neutral is 0%, -50% to 50%
can be selected.
Forward: The servo will jump to the input
position at its maximum possible speed. Unlike
exponential, which adjusts the whole throttle
movement into a curve, throttle acceleration simply
"jumps" away from neutral and then leaves the
remaining response linear.
The initial value of Forward is 0%, 0% to 100%
can be selected. 0% means no acceleration and 100% means approximately 1/2 of the forward
side throttle angle. Operation near the throttle trigger neutral position becomes a sharp rise if
set the value of Forward to 100%.
Brake1/Brake2/Brake3: same as the Forward. The initial value of Brake1/Brake2/Brake3 is 0%,
0% to 100% can be selected. 0% means no acceleration when brake and 100% means brake side
maximum throttle angle. Operation near the throttle trigger neutral position becomes a sharp
rise if set the value of Brake1/Brake2/Brake3 to 100%.

RadioLink RC8X Specifications

General

Channels	8
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Spreading Spectrum	DSSS
Antenna Type	Dual Antenna
Output Signal	PWM, PPM, SBUS
Low Voltage Alert	Yes
Simulator	Yes
Battery Type	LiPo
Voice Alerts	Yes
Display	3.5 inch color screen, 320*480 resolution
Frequency Band	2.4GHz
Operating Voltage	3.5-4.2V
Channel Resolution	4096
Model Type	Helicopter, Airplane, Glider, Multirotor
Compatible Receivers	R8EF, R6FG, R4FGM, R4F
Battery	3.7V 3000mAh LiPo
